DY-855SL技术参数:

DY-855SL机床配置:

1、控制系统：日本 FANUC-0I-MF 数字式控制系统（可选配日本三菱M80系统、华中系统）。

2、三轴驱动电机：全数字式伺服电机。

3、主轴电机：全数字式伺服主轴电机。

4、主轴：台湾罗翌/台大/健椿/爱贝科/德久直联主轴 。

5、自动润滑及润滑报警装置：台湾裕祥/河谷。

6、滚珠丝杆：台湾上银/银泰，精密级滚珠丝杆，C3 级。

7、增压缸：台湾豪澄或臻赏。

8、轴承：日本 NSK ，P4 级、德国。

9、电柜：电柜热交换恒温系统。

10、手脉：日本手持式电子手脉。

11、联轴器：台湾弘旺。

12、冷却泵：渡扬。

13、机身：树脂砂精密机身。

14、刀库：台湾冈田/德速/北钜BT40-24T圆盘刀库。

15、主轴油冷：迪奥特。

16、随机资料：操作编程 铣床、诊断说明、机床使用说明、装箱单。

备注：1.如需特殊配置，请联系技术服务电话，订货时需在订单中专项注明；

2.本公司随时在进行研究改进工作，因此保有随时更改光机技术参数的权力，变更时恕不另行通知。

Product Performance：

DY-850L Vertical machining center adopts advanced design concept and is developed by our engineers with rich experience for many years, which is suitable for China manufacturing and processing industry with excellent cost performance.  And after million times of testina, the equipment has gained market recognition and customer favor.

1、 Precision resin sand casting： The casting is made of

HT300 precision resin sand and cast with high quality cast iron,

so that the machine tool can obtain high rigidity and long-term

Stable precision. And after sufficient secondary processing (tempering, vibration aging) for the machine is not easy to

deform in the perennial use of the machine, can ensure the

Stability of the machine.

2、Highly integrated intelligent electric panel：It is

developed and and uparaded on the basis of traditional electric

cabinet.  It has the advantages of simple wiring, strong dry

tightness  resistance, low failure rate, high reliabilitv and

high operation safety factor.

3、 Advanced numerical control system：This product adopts

FANUC of Japan system, Japan Mitsubishi system,

Huazhong system, Xindai system and other well-known systems,

the system uses modular structure control panel highly

integrated,high reliability, simple and convenient operation.

4、 Famous spindle in Taiwan：The famous spindle imported from

Taiwan is adopted, which has the advantages of high

reliability,low noise, small vibration and high precision. It

is suitable for high precision,high rigidity and high speed

machining.

5、High-speed servo tool magazine：High-speed servo tool magazine realizes high-speed tool change, fast and stable, greatly reduces the non-machining period,and greatly increases the machining efficiency.

6、Guide rail and lead screw： Class C3 high-rigidity pre-tightening ball lead screw of famous brand in Taiwan is adopted, which can realize high-precision position control and ensure the stability of the machine tool. The linear guide rail adopts the P grade guide rail of Taiwan or Germany, which improves the axial running speed of the machine tool and ensures the positioning accuracy of the machine tool.

After-sales Service:

1 Installation and commissioning

1).The buyer shall provide the eguipment installation site and make preparations according to the matters notified by the Supplier in advance.

2）.After the equipment arrives at the factory, conduct unpacking inspection with our company's representative. If any damage or reduction is found, please inform our company immediately.

3).After unpacking and acceptance of the equipment, the Buyer shall first conduct mechanical positioning, cement filling of foundation holes, rough level adjustment and other works, and then fine installation adjustment. The Buyer shall at least notify our company to send personnel in advance.

4). The Buyer is requested to assist the installation and commissioning personnel of our company in arranging accommodation, meals and transportation, etc.

5).The Buyer is requested to designate the operator and maintenance personnel of the machine, and assign special personnel to assist our company in the installation and commissioning of the machine tool. After the mechanical acceptance is completed, the buyer shall sign the machine tool acceptance report in duplicate in real time, and each party shall keep one copy.

2 Acceptance

1). Before installation acceptance, the Buyer shall prepare for installation and commissioning according to installation and commissioning matters.

2).Appearance inspection: The personnel of the Buyer and the Seller shall conduct visual inspection on the appearance, and check and accept according to the Contract and its annexes.

3).Performance and function acceptance: Acceptance shall be carried out according to the scope of supply of machinery and controller determined by both parties.

4).Mechanical accuracy acceptance: The acceptance shall be based on the inspection record sheet of random delivery accuracy provided by our company.

3 Technical training

1）The Supplier shall be responsible for technical training for the Demander, and the training time, place and content shall be based on the contract agreed by both parties (the training time can be conducted during installation and commissioning).

2）The training content is related to the actual project, and the training shall be conducted on the machinery, system, operation, maintenance and other related contents.

4.4 Quality service

1)From the date of final acceptance, 12 months'Three-Guarantee service shall be implemented for the whole product, and free maintenance shall be implemented for the product within the warranty period (only cost fee shall be charged for vulnerable parts, man-made damage and force majeure).

2) During the warranty period, if it is verified that it is the user's fault: The appearance or internal damage of the machinery caused by the loading and unloading and transportation process and the storage time is too long; the human damage caused by improper operation and self-disassembly and modification shall not be covered by the above free warranty, and the user must pay all maintenance and repair expenses. (Note: The damage of equipment caused by natural disasters is not covered by our company's warranty. For example:lightning strike, flood, fire, earthquake, as well as relocation, secondary training, etc.).

3)If the equipment fails and the user information is obtained, the cause and treatment measures of the failure can be accurately judged, the reply shall be given immediately;if the reply cannot be given immediately, reply within 2 hours, and send personnel to the site for treatment as soon as possible. The specific time depends on the preparation time of parts.

4)After the warranty period expires, our company will continue to provide maintenance services for users, and collect the cost of parts and service fees according to our charging standards.

5) If the Buyer fails to perform according to the Contract afteracceptance, the Seller shall have the right to stop after-sales service.

Due to the different configuration, special order, numerical control system and continuous optimization of products, some technical parameters will be affected. Please check according to the actual situation when ordering, and the supply and sales contract shall prevail!In the actual application of the Technical Agreement, the Supplier has the responsibility and obligation to optimize the application of the principle of being responsible for the customer.
